Explain the concept of inheritance in C++ with a simple example.
0 like 0 dislike

Related questions

In C++, what is the fundamental problem that the virtual keyword solves when working with inheritance and pointers, and what is the practical difference in behavior when a base class function is declared with versus without it?
Answer : The `virtual` keyword solves the critical problem of **static vs. dynamic binding**, enabling **runtime polymorphism**, which is arguably the most powerful feature of Object-Oriented Programming. In simple terms, `virtual` ... NOTE: No 'virtual' keyword here void draw() { std::cout ...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

Why is the Fourier Series—the ability to represent a complex periodic function as a sum of simple sine and cosine waves—considered one of the most powerful tools in applied mathematics and engineering?
Answer : The power of the Fourier Series lies in its ability to transform a problem from the often-complex **time domain** into the much simpler and more intuitive **frequency domain**. It acts like a ... ) is impossible. The sharp corners, which rely on the highest frequencies, will always get rounded off....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Explain with the help of a circuit diagram, how the value of an unknown resistance can be determined using a Wheatstone bridge?
Answer : ![][1] [1]: https://electrical-engineering.app/?qa=blob&qa_blobid=407323477172242274 ### **Introduction** A Wheatstone bridge is an electrical circuit used for the precise measurement of an ... (Rā‚ƒ) at the balance point has been recorded, the unknown resistance Rā‚“ can be calculated precisely....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

Explain the choice of size and number of generator units in a power plant.
Answer : --- ### The Fundamental Trade-Off At its core, the decision boils down to a trade-off between two main approaches: 1. **A Few Large Units:** This approach leverages **economies ... designed with multiple, fast-ramping units to complement the variability of wind and solar power on the grid....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

Explain the concept of following terms : (i) Connected load (ii) Maximum demand
Answer : --- ### (i) Connected Load #### Definition **Connected Load** is the sum of the power ratings (in Watts or Kilowatts) of all electrical appliances and equipment installed in a consumer's ... infrastructure (wires, breakers). | **Billing & Grid Management** (demand charges, capacity planning). |...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Stability analysis using Routh-Hurwitz array
Answer : ### **1. The Big Picture: Why Do We Need This?** Imagine you've designed a system-it could be a cruise control for a car, a thermostat for a house, or a robot arm. The most important question you ... further sign changes, it's **Marginally Stable**. If there are sign changes, it's **Unstable**. |...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

In designing an IoT application, what are the key trade-offs between processing data in the Cloud versus at the Edge, and can you provide a real-world example where each approach is clearly superior?
Answer : This question addresses the fundamental architectural choice of "where the thinking happens" in an IoT system. The decision between Cloud and Edge computing directly impacts an application's ... data analytics, and centralized device management. This combination provides the best of both worlds....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

A silver wire has a resistance of 2.1 Ohm at 27.5 degree C , and a resistance of 2.7 Ohm at 100 degree C . Determine the temperature coefficient of resistivity of silver.
Answer : ### 1. Understand the Principle The relationship between resistance and temperature for most metals (like silver) over a moderate temperature range is approximately linear and can be described by the formula: $R_2 = ... 00394 °C⁻¹** Alternatively, in scientific notation: **α = 3.94 x 10⁻³ °C⁻¹**...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

Explain the suitability of copper as an electrical conductor with reference to its mechanical and electrical properties.
Answer : ### Introduction Copper is the industry standard for electrical wiring and conductors, and its widespread use is due to an exceptional combination of both electrical and mechanical properties. While ... for decades, making it the superior choice for the vast majority of electrical applications....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Explain the suitability of aluminum as an electrical conductor with respect to its mechanical and electrical properties.
Answer : Aluminum is an excellent and widely used electrical conductor, second only to copper in global usage. Its suitability is a trade-off: it is not as conductive as copper, but its significantly lower ... at a premium and high conductivity in a small package is essential, copper is the superior choice....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Convert the circuit shown in fig. into a single voltage source in series with resistance. ![][1] [1]: https://electrical-engineering.app/?qa=blob&qa_blobid=17118069873838951895
Answer : ![][1] [1]: https://electrical-engineering.app/?qa=blob&qa_blobid=10997850983763419494 --- ### **Mastering Source Transformation: A Step-by-Step Circuit Simplification Example** Source transformation is a ... **30/31 Ī© (or approximately 0.97 Ī©) resistor**. **Final Circuit Diagram:** ...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Using source conversion, reduce the circuit shown in the figure into a single voltage source in series with a single resistance. ![][1] [1]: https://electrical-engineering.app/?qa=blob&qa_blobid=18414686426985693295
Answer : ![][1] [1]: https://electrical-engineering.app/?qa=blob&qa_blobid=9298562401596151803 ### **Source Transformation Explained: A Step-by-Step Circuit Simplification Example** Source ... a resistor is a Norton equivalent circuit. Source transformation is the method to convert between them....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Describe with sketches the process of laying of underground cables by the drawing in method.
Answer : ### **The "Drawing In" Method for Laying Underground Cables** This method involves first installing a system of pipes or conduits (called ducts) underground. The cables are then pulled, or " ... duct system. However, this is often offset by the long-term flexibility and protection it provides....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

State why the resistance of the conductor increases with the rise in temperature.
Answer : Here is a clear explanation of why the resistance of a conductor increases with a rise in temperature, broken down into a simple analogy and the underlying physics. --- ### Simple Analogy: The ... More collisions** mean more opposition to the flow, which is, by definition, **higher resistance**....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Draw the graph showing the variation of conductivity with temperature for a metallic conductor?
Answer : The conductivity for a metallic conductor decreases with the increase in temperature. ![][1] [1]: https://electrical-engineering.app/?qa=blob&qa_blobid=10491891827766109637 ### Explanation: The Physics Behind the Graph To understand this ... | **Low** |...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

Explain the reasons for failure of gaseous and solid dielectric materials used in electrical engineering application.
Answer : ### **Introduction to Dielectric Failure** A dielectric material is an electrical insulator that can be polarized by an applied electric field. Its primary function in electrical engineering is to ... Often a slow, aging-related process - Highly sensitive to impurities, voids, and moisture |...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Explain the use of the following components in electrical wiring system and give specification of each: (i) MCB (ii) ELCB
Answer : ### Introduction In any modern electrical wiring system, safety and protection are paramount. Devices like MCBs and ELCBs are critical safety components installed in a consumer unit (also known as a ... (lighting, sockets, etc.) | Protecting a group of circuits or an entire installation |...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Explain the uses of safety rubber hand gloves and rubber mats in electrical engineering.
Answer : In electrical engineering, safety is paramount. Two of the most fundamental and critical pieces of Personal Protective Equipment (PPE) are **safety rubber hand gloves** and **insulating rubber ... environment and preventing a worker's body from becoming the path of least resistance for electricity....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Explain the use of following tools in carrying out electrical wiring installation: (i) Nose pliers (ii) Test lamps (iii) Crimping tools (iv) Cutter.
Answer : General Introduction In electrical wiring, using the correct tool for the job is not just about efficiency; it is a fundamental requirement for safety and the quality of the finished installation. A poor ... Do not use them to cut steel wire or screws, as this will damage the cutting edges....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

X Full Screen Image
Electrical Engineering

Loading products...

In a Hall Effect experiment, a voltage is measured perpendicular to both the current flow and the magnetic field. What is the physical origin of this "Hall Voltage," and what two crucial properties of a semiconductor material can be determined by measuring it?
Answer : The physical origin of the Hall Voltage is the **Lorentz force** acting on charge carriers as they move through a magnetic field. This simple experiment is profoundly important because it ... **carrier concentration `n`**, a fundamental parameter that dictates the material's electrical properties....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

What is the multipath fading problem in wireless communication, and how does the Orthogonal Frequency-Division Multiplexing (OFDM) modulation scheme elegantly solve this problem, which was a major limitation for previous generations of mobile technology?
Answer : This question addresses the single most challenging physical problem in mobile communication and the ingenious solution that underpins virtually all modern broadband wireless standards. --- ### **Part 1: The Problem - Multipath Fading and ... **4G LTE, 5G NR, and modern Wi-Fi (Wi-Fi 4/5/6/7)**....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

A steady current flow in a metallic conductor of non-uniform crosssection. Which of these quantities is constant along the conductor: current, current density, electric field, drift speed?
Answer : Here is a detailed explanation for each quantity: ### 1. Current (I) * **Why it's constant:** The term "steady current" implies that the rate of flow of charge ($I = dQ/dt$) is constant. Due to the ... ($v_d$)** | Not Constant | $v_d = I/(nAe)$. Since A is not constant, $v_d$ is not constant. |...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Six lead-acid type of secondary cells each of emf 2.0 V and internal resistance 0.015 Ohm are joined in series to provide a supply to a resistance of 8.5 Ohm . What is the current drawn from the supply and its terminal voltage?
Answer : ### Given Data: * Number of cells, **n = 6** * EMF of each cell, **E_cell = 2.0 V** * Internal resistance of each cell, **r_cell = 0.015 Ī©** * External resistance (load), **R = 8.5 Ī© ... The current drawn from the supply is **1.40 A**. * The terminal voltage of the supply is **11.9 V**....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

A storage battery of emf 8.0 V and internal resistance 0.5 Ohm is being charged by a 120 V DC supply using a series resistor of 15.5 Ohm . What is the terminal voltage of the battery during charging? What is the purpose of having a series resistor in the charging circuit?
Answer : ### Given Data: * Electromotive force (emf) of the battery, $E = 8.0 \text{ V}$ * Internal resistance of the battery, $r = 0.5 \text{ } \Omega$ * DC supply voltage, $V_{supply} = ... to a much safer and more manageable **7.0 A**, protecting both the battery and the power supply from damage....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

A battery of emf 10 V and internal resistance 3 Ohm is connected to a resistor. If the current in the circuit is 0.5 A, what is the resistance of the resistor? What is the terminal voltage of the battery when the circuit is closed?
Answer : ### Given Information: * **EMF of the battery (E):** 10 V * **Internal resistance (r):** 3 Ī© * **Current in the circuit (I):** 0.5 A --- ### 1. What is the resistance of the ... text{V}$ Both methods give the same result. **Answer:** The terminal voltage of the battery is **8.5 V**....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Three identical cells, each of emf. 2V and unknown internal resistance are connected in parallel. This combination is connected to a 5 ohm resistor. If the terminal voltage across the cell is 1.5 volt. What is the internal resistance of each cell? Hence define the internal resistance of a cell?
Answer : ### Part 1: Calculating the Internal Resistance Here's how we can find the internal resistance of each cell. **Given Data:** * Electromotive force (EMF) of each cell, E = 2 V * Number of identical cells ... . * **I** is the current flowing from the cell. * **r** is the internal resistance....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

In a potentiometer arrangement, a cell of emf 1.25V gives a balance point at 35.0cm length of the wire. If the cell is replaced by another cell and the balance point shifts to 63.0cm , what is the emf of the second cell?
Answer : ### Principle The working principle of a potentiometer is that the potential drop across any portion of a wire of uniform cross-section is directly proportional to the length of that portion, provided a constant current flows ... 2.25 V** ### Answer The EMF of the second cell is **2.25 V**....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

A set of n-identical resistors, each of resistance R ohm when connected in series have an effective resistance of X ohm and when the resistors are connected in parallel the effective resistance is Y ohm. Find the relation between R , X and Y ?
Answer : Let's break this down step-by-step to find the relationship between R, X, and Y. ### 1. Resistors in Series When resistors are connected in series, their total effective resistance is the sum of ... the **geometric mean** of the total series resistance (X) and the total parallel resistance (Y)....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Two heated wires of the same dimensions are first connected in series and then it’s parallel to a source of supply. What will be the ratio of heat produced in the two cases?
Answer : Here is the step-by-step solution: ### The Short Answer The ratio of heat produced in the series case to the parallel case is **1:4**. --- ### Detailed ... proportional to this current, the parallel circuit draws significantly more power and therefore produces significantly more heat....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Two wires A and B are of the same metal and of same length have their areas of cross section in the ratio 2:1 if the same potential difference is applied across each wire in turn, what will be the ratio of current flowing in A & B ?
Answer : The ratio of the current flowing in wire A to wire B is **2:1**. --- ### Detailed Explanation Let's break down the problem using the relevant physics principles. #### 1. List the Given ... resistance, which is wire A. Our result confirms this: the current in A is twice the current in B....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

If the temperature of a good conductor decreases, how does the relaxation time of electrons in the conductor change?
Answer : ### The Short Answer If the temperature of a good conductor decreases, the **relaxation time of electrons increases**. --- ### The Detailed Explanation To understand why, let's break ... **. This is why good conductors become even better conductors (less resistive) at lower temperatures....

Show More
X Full Screen Image
Electrical Engineering

Loading products...

Find the Thevenin equivalent circuit of the circuit shown in Fig. to the left of the terminals a-b. Then find the current through RL = 6, 16, and 36 Ohm. ![][1] [1]: https://electrical-engineering.app/?qa=blob&qa_blobid=8797772883006435339
Answer : Solution : ![][1] [1]: https://electrical-engineering.app/?qa=blob&qa_blobid=9419660387739356857...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

With a neat diagram explain solar photovoltaic power plant.
Answer : Diagram of solar photovoltaic power plant : ![][1] [1]: https://electrical-engineering.app/?qa=blob&qa_blobid=4390643679587391452 Explanation: Solar power plant consists of following components: 1. ... 5. Step-up transformer: It step-up input voltage to utilization voltage e.g. 230V ...

Show More
X Full Screen Image
Electrical Engineering

Loading products...

With a neat diagram explain medium head hydro-electric power plants.
Answer : ### **Medium-Head Hydro-Electric Power Plant** A medium-head hydro-electric power plant operates with a "head" (the vertical distance the water falls) typically ranging from **30 meters to 300 meters* ... **Tailrace:** The channel that carries water away from the powerhouse and back to the river....

Show More
X Full Screen Image
Electrical Engineering

Loading products...
