In a Hall Effect experiment, a voltage is measured perpendicular to both the current flow and the magnetic field. What is the physical origin of this "Hall Voltage," and what two crucial properties of a semiconductor material can be determined by measuring it?

0 like 0 dislike

1 Answer

The physical origin of the Hall Voltage is the Lorentz force acting on charge carriers as they move through a magnetic field. This simple experiment is profoundly important because it allows us to directly measure two of the most fundamental properties of a conducting or semiconducting material: the sign (type) of the majority charge carriers and their concentration (density).


Part 1: The Physical Origin of the Hall Voltage

Let's visualize the standard lab setup:
1. A thin, flat, rectangular sample of a semiconductor (like silicon).
2. A current, I, is passed along its length (let's say, in the +x direction).
3. A uniform magnetic field, B, is applied perpendicular to the sample's flat face (in the +z direction).

Here's the step-by-step physics of what happens inside the material:

  1. Charge Carriers in Motion: The current consists of charge carriers (let's assume they are electrons for now) moving with an average drift velocity, v. Since electrons are negatively charged, their velocity is opposite to the conventional current (in the -x direction).

  2. The Lorentz Force: Any charged particle (q) moving with velocity (v) through a magnetic field (B) experiences a Lorentz force, given by the vector cross product: F = q(v × B).

  3. Deflection of Charges: Using the right-hand rule for the cross product (v × B), the electrons moving in the -x direction through a +z magnetic field are deflected by a magnetic force towards one side of the sample (the -y side).

  4. Charge Accumulation and Equilibrium:
    This magnetic force causes electrons to pile up along one edge of the semiconductor.
    This accumulation of negative charge on one side leaves a net positive charge (due to the fixed, ionized atoms in the crystal lattice) on the opposite edge.
    * This separation of charge creates a transverse electric field, E_H (the Hall Field), pointing from the positive edge to the negative edge.

  5. The Balancing Act: This new Hall Field exerts an opposing electric force, F_E = qE_H, on the charge carriers. The charge accumulation continues until this electric force perfectly balances the magnetic force. At this point of equilibrium:
    Magnetic Force = Electric Force
    q v B = q E_H

  6. Measuring the Hall Voltage: This transverse electric field, E_H, creates a potential difference across the width (w) of the sample. This measurable potential difference is the Hall Voltage (V_H).
    V_H = E_H × w


Part 2: The Two Crucial Properties Determined

This simple voltage measurement is incredibly powerful.

1. The Sign (Type) of the Majority Charge Carriers

This is perhaps the most elegant result of the experiment. The polarity of the Hall Voltage directly tells you whether the dominant charge carriers are negative electrons or positive "holes."

  • For an N-type semiconductor (carriers are electrons, q = -e): Electrons are pushed to one side, making that side negative relative to the other. The voltmeter will read a Hall Voltage of a certain polarity.
  • For a P-type semiconductor (carriers are holes, q = +e): Positive holes move in the same direction as the current (+x). The Lorentz force pushes these positive charges to the same side as it pushed the electrons. This makes that side positive relative to the other. The voltmeter will read a Hall Voltage with the opposite polarity.

Therefore, by simply checking the sign (+ or -) of the measured V_H, we can definitively determine if the material is N-type or P-type, a critical distinction in semiconductor engineering.

2. The Carrier Concentration (Density)

This is the quantitative result. We can calculate n, the number of charge carriers per unit volume.

Starting from the equilibrium condition v B = E_H:
We know E_H = V_H / w (where w is the width).
We also know the formula for current: I = n q A v, where n is the carrier concentration, A is the cross-sectional area (A = w × t, where t is the thickness), and q is the elementary charge.
* We can rearrange this to find the drift velocity: v = I / (n q w t).

Now, substitute these into the equilibrium equation:
(I / (n q w t)) × B = V_H / w

By simplifying and rearranging to solve for n, we get the Hall Effect equation:
$$ n = \frac{I \cdot B}{V_H \cdot q \cdot t} $$

This means that by measuring the input current (I), the magnetic field strength (B), the sample thickness (t), and the resulting Hall Voltage (V_H), we can calculate the carrier concentration n, a fundamental parameter that dictates the material's electrical properties.

0 like 0 dislike
